Gulfstream 28 X Boat Plans (GS28X)

[GS28X] An economical and seaworthy large inboard powered sport fishing boat. Many options.


SKU: GS28X-Plans Category:


The GulfStream 28 X is a variation of the standard GS28. We kept the standard GS28 plans as simple as possible: one hull material, simple hull shape, one layout and one type of motorization. We present a number of options as a separate plan under the name GS28X.

In addition to all the features present in the standard GS28, the X version offers the following options:

hull material: plywood cored epoxy or foam sandwich
hull shape variations: flared bow, closed transom for bracket, rounded transom for stern-drive, optional skeg keel for the stern-drive version
propulsion: outboards with or without bracket, stern-drive inboard gas or diesel.
layouts: open cockpit or forward cabin (“jump cabin”).
The builder can combine most of those options.

Click here to see study plans

Related Kits:

CNC Kit – MarinEpoxy Kit – SilverTip Epoxy Kit


Additional information

Weight N/A
Dimensions N/A

LOA: 28' ( 28' 4" with rounded transom) 8,54 m Max. Beam: 8' 2" 2,49 m Hull draft at DWL: 14.5" 37 cm Displacement at DWL: 5,000 lbs 2267 liters PPI at DWL: 727 lbs/in 130 kg/cm Fuel: 85 to 120 gallons 340 to 480 liters Recommended. HP 125 to 300 HP 93 to 225 Kw Material: Plywood cored epoxy composite or foam sandwich
